20 x 2 Graphic Lcd Dot Matrix Display Module 2002 Lcd Display For Instrument


A. Specifications:



Number of characters: 20 characters x 2 lines
Display type: COB STN/FSTN, blue/gray/yellow green, negative/positive
Duty: 1/16
Bias: 1/5
Input voltages: 5.0 or 3.3V DC
Viewing angle: 6 or 12 O'clock
Connector: zebra
LED backlight color: white/blue/yellow green

ITEM
CONTENT
DESCRIPTION
1
Display Outline Size
116 ( H ) * 37 ( W ) * 12.5 mm ( T )
2
Viewing Size
85 ( H ) * 20 (W) mm
3
Voltage
3.3 V , 5.0V
4
Operation Temperature
-20~70℃
5
Storage Temperature

-30~80℃

6
Backlight
White Led
7
Color
Blue or Yellow - Green
8
Drive IC
ST7920



B. Product Details:

  • Suitbale for copiers, fax machines, industrial test equipment, networking, etc
  • This product is a LCD display module with blue backlight
  • 2002 LCD display module is a great replacement for the old one
  • Small and light appearance, it is easy and convenient to use
  • Other features: 5V logic power supply, parallel communication, high reliability, wide temperature range.

20 x 2 Graphic LCD Dot Matrix Display Module 2002 For Instrument 0

C. Structure Diagram:



The display is a critical component in every project, impacting the case, firmware, electrical design, user interface, and even battery life. For these reasons, and because it is the most visible component of your product, it must be approved by the mechanical design team, management and marketing.Before these teams can approve, they need to see it in action. But it can take days or weeks to connect a display to your platform, initialize it and build a code library able to create believable demonstrations. Meanwhile, the whole project is on hold.Our 8051 development kit / demonstration board can solve this problem. Use it to get the display seen, demonstrated and approved for your project.

2002A is a microcontroller 8051(80C51) demonstration and development kit for 2002A series product that is 20x2 character lcd module.The kit includes MCU board controlled, ISP(In System Programming) with USB port and cable to customize the demonstration that includes your own bitmap images,personalized fonts,symbols,icons and burn sketches,the power supply,the crimping tool used to connect display and MCU board.Optional for 6800 4/8-bit parallel interface.


 20 x 2 Graphic LCD Dot Matrix Display Module 2002 For Instrument 1


2002A is 20 characters wide,2 rows character lcd module,SPLC780C controller (Industry-standard HD44780 compatible controller),6800 4/8-bit parallel interface,single led backlight with yellow green color included can be dimmed easily with a resistor or PWM,stn-lcd positive,dark blue text on the yellow green color,wide operating temperature range,rohs compliant,built in character set supports English/Japanese text, see the SPLC780C datasheet for the full character set.Optional 3.3v or 5v power supply and optional pin header connection.

It's easily controlled by MCU such as 8051,PIC,AVR,ARDUINO,ARM and Raspberry Pi.It can be used in any embedded systems,industrial device,security,medical and hand-held equipment.
