2.0 Inch TFT Lcd Transflective Display 240 * 320 Dots Small Lcd Module With Mcu / Spi / Rgb Interface

Basic Information
Place of Origin: Dongguan,China
Brand Name: Fangsheng
Certification: ISO9001:2015
Model Number: FS2010-22PJPY
Minimum Order Quantity: 1 Piece
Price: USD 7.5 - 9.5 / Piece
Packaging Details: Bubble Bag + Blister + Foam Box + Carton
Delivery Time: 3~5 Working Days
Payment Terms: L/C, T/T, D/A, D/P, Western Union, Paypal
Supply Ability: 200K Sets / Month
Detail Information
Resolution: 240 * 320 Size: 2.0 Inch
Viewing Direction: 12 O ' Clock TFT Mode: TFT, Transmissive
Outline Size: 35.95 * 51.7 Mm * 2.45 T Brightness: 160Cd / M2
Type: LCM, TFT, COG
High Light:

tft touch screen display

,

tft lcd panel


Product Description

FT2010JPY-22P-fancy.pdf 2.0 Inch TFT Lcd Transflective Display 240 * 320 Dots Small Lcd Module With Mcu / Spi / Rgb Interface

A. Specifications:

Item
Contents
Description
1
Product Name
2.0 Inch Transflective TFT Lcd Display 240 * 320 Dots
2
Module Size
35.95 mm * 51.7 mm * 2.45 mm T
3
Resolution
240 * 320
4
Panel Type
a-si TFT
5
View Angle
12 O ' Clock
6
Interface Type
RGB 6Bit Interface
7
Pins Number
22 Pins
8
Controller / Driver
ST7789V


Our Advantage:


1 . Factory direct price.
2 . Good quality.
3 . Quick shipping within 5 days.
4 . For stocks, no moq , 1pc ok . small order welcome..
5 . Online payment.
6 . Support 7 days refund.
7 . After sales services 24 hours / 7 days



Our Certificates:


1. GB/T19001-2016 idt ISO9001:2015
2. CE & ROHS
3. SGS of LCD Display


FS2020-22PJPY
is 240 * 320 dots color TFT Lcd Module with ST7789V controller. We promise the long term continuity supply for this product no less than 17 years since 2001.



B. Product Applications:
2.0 Inch TFT Lcd Transflective Display 240 * 320 Dots Small Lcd Module With Mcu / Spi / Rgb Interface 0


C. Structure Diagram:

2.0 Inch TFT Lcd Transflective Display 240 * 320 Dots Small Lcd Module With Mcu / Spi / Rgb Interface 1

Pin Definistion:

2.0 Inch TFT Lcd Transflective Display 240 * 320 Dots Small Lcd Module With Mcu / Spi / Rgb Interface 2

Fangsheng
is a high-tech company specializing in R&D, production and sales of LCD and LCM since 2001. Our company boasts a professional team with years of experience in the LCD technology, and has established a perfect quality and a management system.We will spare no effort in innovation and lean manufacturing.
