HTN LCD Display PIN Connector Segment Type HTN LCD for Instruments and Meters Custom LCD Display

HTN LCD Display PIN Connector Segment Type HTN LCD for Instruments and Meters Custom LCD Display

HTN LCD display for instruments

custom HTN LCD connector

segment type HTN LCD

Place of Origin:

Dongguan,China

Brand Name:

Fangsheng

Certification:

ISO9001:2015,IATF16949,RoHS,Reach,etc

Model Number:

FS-HTN

Contact Us
Request A Quote
HTN LCD Display PIN Connector Segment Type HTN LCD for Instruments and Meters Custom LCD Display HTN LCD Display PIN Connector Segment Type HTN LCD for Instruments and Meters Custom LCD Display HTN LCD Display PIN Connector Segment Type HTN LCD for Instruments and Meters Custom LCD Display HTN LCD Display PIN Connector Segment Type HTN LCD for Instruments and Meters Custom LCD Display
Product Details
Product Name:
HTN LCD Display PIN Connector Segment Type HTN LCD For Instruments And Meters Custom LCD Display
Display Type:
HTN,negative Mode
Connector Type:
PIN(Customized)
Interface Type:
Parallel Interface,SPI,RS232,MCU,etc
Viewing Direction:
6 O’clock(Customized)
Operating Voltage:
5V (Customized)
Highlight:

HTN LCD display for instruments

,

custom HTN LCD connector

,

segment type HTN LCD

Payment & Shipping Terms
Minimum Order Quantity
1000
Price
$0.1-$8
Packaging Details
Bubble Bag + Blister + Foam Box + Carton
Delivery Time
25-30 DAYS
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram,
Supply Ability
200K Sets / Month
RELATED PRODUCTS
Good price HTN LCD Display PIN Connector Segment Type HTN LCD for Instruments and Meters Custom LCD Display online

HTN LCD Display PIN Connector Segment Type HTN LCD for Instruments and Meters Custom LCD Display

Get Best Price
Good price Custom ROHS Compliant HTN Segment LCD 7 Segment LCD Display for Industrial Control online

Custom ROHS Compliant HTN Segment LCD 7 Segment LCD Display for Industrial Control

Get Best Price
Good price Custom Segment LCD Display for Instruments Custom HTN LCD Display with Backlight online

Custom Segment LCD Display for Instruments Custom HTN LCD Display with Backlight

Get Best Price
Good price Metal PIN LCD Digital Display / HTN Positive Transflective Segment LCD Display online video

Metal PIN LCD Digital Display / HTN Positive Transflective Segment LCD Display

Get Best Price
Contact Us
+86 136 3170 3190
fssales03@fsdzlcd.com
86-769-2270-5825
Contact Now
Product Description
HTN LCD Display PIN Connector Segment Type HTN LCD for Instruments and Meters Custom LCD Display
Product Specifications
Attribute Value
Product name HTN LCD Display PIN Connector Segment Type HTN LCD for Instruments and Meters Custom LCD Display
Display Type HTN, negative mode
Connector Type PIN (Customized)
Interface type Parallel Interface, SPI, RS232, MCU, etc
Viewing Direction 6 o'clock (Customized)
Operating Voltage 5V (Customized)
Technical Specifications
Parameter Specification Description
Display Mode HTN, Negative High Transmissive Nematic, Negative mode (dark characters on bright background)
Drive Condition 1/4 Duty, 1/3 Bias LCD driving method and bias ratio
Viewing Direction 6 O'Clock Optimal viewing angle from bottom
Operating Temperature -30°C to +80°C Temperature range for normal operation
Storage Temperature -40°C to +85°C Safe storage temperature range
Operating Voltage 5.0 V Typical operating voltage
Frame Frequency 64 Hz LCD driving frame rate
Front Polarizer Transmissive, Adhesive Type and adhesive of front polarizer
Back Polarizer Transflective, Adhesive Type and adhesive of back polarizer
Connectors PIN Interface type
Key Features
HTN LCD Display PIN Connector Segment Type HTN LCD for Instruments and Meters Custom LCD Display 0
  • Simple and Clear Display - Ideal for showing numbers, letters, or basic symbols with high readability.
  • Low Power Consumption - Uses minimal energy, making it perfect for battery-powered devices.
  • Cost-Effective Solution - Economical choice for small-scale displays compared to graphic screens.
  • Durable and Long-Lasting - Resistant to long-term usage and environmental factors.
  • Easy Integration - Can be embedded into electronic devices like meters, medical instruments, and appliances.
