7 Inch TFT Lcd Module Lcd Display MCU Interface Lcd With PCB Control Board for Raspberry Pi 3




FST070480R-70 is a 7.0 TFT dot matrix LCD module.
It is composed of a PCBA,color-LCD panel(7.0),RTP(7.0), driver IC, FPC and a backlight unit. The module display area contains 800x480 pixels. This product accords with RoHS environmental criterion.


7 Inch TFT LCD Module MCU Interface With PCB Control Board For Raspberry Pi 3 0






Product Details:

Each LCD will be tested one by one with our device before shipping to make sure the lcd will works perfect on your device,if you don't know how to install it,we suggest you to find a professional technician to do for you.Installation guide not provide, please be sure you know how to install it before bid.



PINs Connect

7 Inch TFT LCD Module MCU Interface With PCB Control Board For Raspberry Pi 3 1


Specifications:



Driven by Raspberry Pi (linux) & win7/win8/win10 systems

ITEM
CONTENT
DESCRIPTION
1
Display outline size
180 ( H ) * 104 ( W ) * 12 mm ( T )
2
VA size
165 * ( H ) * 100( W ) mm
3
Resolution
800 RGB ( H ) x 480 ( V )
4
With /Without Touch screen
Capacitvie Touch
5
Interface
MCU - SPI 4 Wire
6
Backlight
24 Led
7
Color
65k 262K
8
Drive IC
RA8875

Structure Diagram:

Controller driver board, MCU SPI Interface board, LCD cable and connector)
