7 Segment TN LCD Display / Reflective LCD Module For Electronic Water Meter
Product Details:
| Place of Origin: | Dongguan, China |
| Brand Name: | Fangsheng |
| Certification: | ISO9001:2015 |
| Model Number: | FHP2471RF01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 500 |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Bubble bag + Blister + Foam box + Carton |
| Delivery Time: | 7-10 Working Days |
| Payment Terms: | T/T , Western Union , Paypal , Credit Card , D/A , D/P , L/C |
| Supply Ability: | 200K Sets / Month |
|
Detail Information |
|||
| Type: | TN Lcd Display | Backgound: | Yellow |
|---|---|---|---|
| Voltage: | 3.0V | Connector: | FPC |
| Driving Method: | 1 / 4 Duty , 1 / 3 Bias | Polarizer Type: | Reflective |
| High Light: | tn lcd module,tn panel display |
||
Product Description
7 Segment Lcd Screen TN Lcd Display Reflective Lcd Module For Electronic Water Meter
Technical parameters:
1. LCD Screen Material: Glass is main material;
2. LCD Display Structure: Polarizer,electrode,Polymer,ITO,Reflector;
3. Display Type: FSTN, STN, VA, HTN, TN;
4. LCD Display Mode: Positive display,Negative display
5. Viewing Angle: 3 o’clock, 6 o’clock, 9 o’clock, 12 o’clock;
6. The ITO thickness normal value: 0.4mm, 0.55mm, 0.7mm, 1.1mm;
7. Connector Type: Metal stitch, electroconductive rubber, heat-seal connector;
8. Transmission of light Type: reflecting type, transmission type, half transmission;
9. Backlight: LED backlight, EL backlight, CCFL backlight;
10.Operation Temperature: -40℃~+90℃ Over Wide Temperature
| ITEM | CONTENT | DESCRIPTION |
| 1 | Lcd Type | TN Segnement Lcd Display |
| 2 | Outline Size | 44mm ( L ) * 18mm ( W ) * 1.1mm T |
| 3 | VA Size | 41mm ( L ) * 12mm ( W ) |
| 4 | Viewing Direction | 6 O ' clock |
| 5 | Voltage | 3.0V |
| 6 | Display Mode | Positive |
| 7 | Polarizer Mode | Reflective |
| 8 | Operation temp | - 20°C to + 70°C |
| 9 | Storage temp | - 30°C to + 80°C |
| 10 | LED Connect | FPC |
Duty cycle
This parameter is also known as Duty number or COM number. Because STN/TN LCD is usually driven by time-division dynamic scanning mode, in this mode, the ratio of the effective turn-on time of each COM to the whole scan cycle, i.e. Duty, is fixed, equal to 1/COM number. Bias: Bias
The driving waveform of SEG/COM of LCD is analog signal, and the ratio of analog voltage to the maximum output voltage of LCD is called bias. Generally speaking, Bias is expressed by the ratio of the lowest output voltage to the highest output voltage. Generally speaking, there is a certain relationship between Bias and Duty. The more the number of Duty, the shorter the scanning time of each COM. To achieve the same display brightness and contrast, the voltage of VON will be increased, and the difference between the selection level and the non-selection level needs to be increased, that is, Bias needs to be increased. There is an empirical formula between Duty and Bias, that is, to achieve the same display brightness and contrast.
Application:
FHP2471RF01 is TN Lcd Display to be use on Electronic Water Meter, Instrument, Humidity etc.
